Low-Height Hydraulic Jack Featuring a flat, low-profile design ideal for confined space operations. The grooved spindle surface eliminates the need for additional spacer blocks. Hard chrome-plated spindle and inner walls provide excellent wear and corrosion resistance. Powerful springs accelerate spindle return speed. Dust rings reduce contamination buildup, while top nuts protect against over-stroke. All models include M16 x 1.5 quick couplings and dust caps. Perfect for applications requiring maximum lifting in minimal clearance.

KX Series Hollow Hydraulic Jack The KX hollow hydraulic jack features a hollow plunger design ideal for both pushing and pulling applications. It can sustain maximum load capacity at full stroke. Special hollow bushings protect the spindle and inner walls, extending product lifespan. Premium imported sealing materials ensure superior sealing, while hard chrome-plated spindles provide excellent wear and corrosion resistance. Available in single and double-acting models. All units include NPT3/8 quick couplings and dust caps.

Lighter and shorter collapsed height than equivalent RACH single-acting models Double-acting for rapid retraction, regardless of hose lengths or system losses Built-in safety valve prevents accidental overpressurization Hollow plunger design allows for both pull and push forces Composite bearings increase cylinder life and side load resistance Hard coat finish on all surfaces resists damage and extends cylinder life Handles included on all models Floating center tube increases seal life Steel baseplate and saddle for protection against load-induced damage Integral stop ring prevents plunger over-travel and is capable of withstanding the full cylinder capacity CR400 coupler and dust cap included on all models All cylinders meet ASME B-30.1 standards
